Mobilgear 600 XP Series

Gear Oil

The Mobilgear 600 XP Series are extra high performance gear oils having outstanding extreme pressure characteristics and load-carrying properties, intended for use in all types of enclosed gear drives with circulation or splash lubrication systems. Mobilgear 600 XP Series is designed to stay ahead of the changing needs of gearbox technology. Gearbox technology design trends are towards smaller units with similar power throughput. This increase in power density places increased demands on gear oils. Mobilgear 600 XP Series oils are formulated to meet the stress by providing extra protection for gears, bearings and seals.



Mobilgear 600 XP Series is formulated to protect gear teeth from wear at its earliest stages. Microscopic wear, called micropitting, can lead to significant gear tooth damage. Mobilgear 600 XP Series exceeds the industry requirement for bearing wear protection. In fact, Mobilgear 600 XP Series provides up to 15 times the wear protection as measured by the industry standard FAG FE 8 test. Mobilgear 600 XP Series' balanced formulation is able to provide maximum wear and corrosion protection while maintaining compatibility with common gearbox seal materials. Mobilgear 600 XP helps to maintain gearbox seal integrity thereby preventing oil leaks and keeping contamination out. By protecting the gears, bearings and seals, Mobilgear 600 XP can improve equipment reliability and increase productivity.



Mobilgear 600 XP Series oils are recommended for industrial spur, helical and bevel enclosed gears with circulation or splash lubrication, operating at bulk oil temperatures up to 100ºC. They are particularly suitable for gear sets working under heavy or shock loads. Mobilgear 600 XP oils also find broad application in marine gearing applications. They may also be used in non-gear applications include highly loaded and slow speed plain and rolling contact bearings.



Features and Benefits

Mobilgear 600 XP Series products are a leading member of the Mobil brand of industrial lubricants that enjoy a reputation for innovation and high performance capability. These mineral-based products are designed to provide high quality industrial gear oils, meeting the latest industry standards and with high versatility to lubricate a broad range of industrial and marine equipment.



Mobilgear 600 XP Series products offer the following features and potential benefits:



Features

Advantages and Potential Benefits

Enhanced gear wear protection from micropitting

Less gear and bearing wear resulting in less unexpected downtime

Reduced debris denting from generated wear particles

Up to 22% improvement in bearing life reducing bearing replacement costs and improving productivity

Improved bearing wear protection

Improved bearing life resulting in higher productivity

Outstanding compatibility with a range of seal materials

Reduced leakage, oil consumption and contamination ingress helping to reduce maintenance, extend gearbox reliability and higher productivity

Excellent resistance to oil oxidation and thermal degradation

Helps extend lubricant life with lower lubricant and lubrication costs and reduced scheduled downtime.

High resistance to sludge and deposit formation

Cleaner systems and reduced maintenance

Wide range of applications

Fewer grades of lubricant required because of wide range of application, leading to lower purchase and storage costs and less danger of using wrong lubricant

Optimised resistance to rust and corrosion of steel and corrosion of copper and soft metal alloys

Excellent protection of machine parts, with reduced maintenance and repair costs

Resistance to foaming and emulsion formation

Effective lubrication and problem free operation in the presence of water contamination or in equipment prone to oil foaming



Applications

Mobilgear 600 XP lubricants are used in a wide range of industrial and marine applications, especially spur, helical, bevel and worm gearing. Specific applications include:

     •  Industrial gearing for conveyers, agitators, dryers, extruders, fans, mixers, presses, pulpers, pumps (including oil well pumps), screens, extruders and other heavy duty applications

     •  Marine gearing including main propulsion, centrifuges, deck machinery such as winches, windlasses, cranes, turning gears, pumps, elevators and rudder carriers

     •  Non-gear applications include shaft couplings, screws and heavily loaded plain and rolling contact bearings operating at slow speeds.

     •  Mobilgear 600 XP 100, 150, 220, 320, 460, and 680 are approved by Siemens AG for use in Flender gearboxes



Specifications and Approvals

This product has the following approvals:

68

100

150

220

320

460

680

Mueller-Weingarten DT 55 005 - CLP 100

X

Mueller-Weingarten DT 55 005 - CLP 150

X

Mueller-Weingarten DT 55 005 - CLP 220

X

Mueller-Weingarten DT 55 005 - CLP 320

X

Mueller-Weingarten DT 55 005 - CLP 460

X

Siemens Flender Gears, T 7300, A-a, code A12

X

Siemens Flender Gears, T 7300, A-a, code A13

X

Siemens Flender Gears, T 7300, A-a, code A14

X

Siemens Flender Gears, T 7300, A-a, code A15

X

Siemens Flender Gears, T 7300, A-a, code A16

X

Siemens Flender Gears, T 7300, A-a, code A17

X



This product meets or exceeds the requirements of:

68

100

150

220

320

460

680

AGMA 9005-E02-EP

X

X

X

X

X

X

DIN 51517-3:2009-06

X

X

X

X

X

X

X

ISO L-CKC (ISO 12925-1:1996)

X

ISO L-CKD (ISO 12925-1:1996)

X

X

X

X

X

X



Properties and Specifications

Property

68

100

150

220

320

460

680

Grade

ISO 68

ISO 100

ISO 150

ISO 220

ISO 320

ISO 460

ISO 680

Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130

1B

1B

1B

1B

1B

1B

1B

Density @ 15.6 C, kg/l, ASTM D4052

0.88

0.88

0.89

0.89

0.9

0.9

0.91

EP Properties, Timken OK Load, lb, ASTM D2782

65

65

65

65

65

65

65

Emulsion, Time to 37 mL Water, 82 C, min, ASTM D1401

30

30

30

30

30

30

30

FE8 wear test, V50 roller wear, mg, DIN 51819-3

2

2

2

2

2

2

2

FZG Micropitting, Fail Stage, Rating, FVA 54

10 / High

10 / High

10 / High

10 / High

10 / High

10 / High

FZG Scuffing, Fail Load Stage, A/16.6/90, ISO 14635-1(mod)

12+

12+

12+

12+

12+

12+

FZG Scuffing, Fail Load Stage, A/8.3/90, ISO 14635-1

12+

12+

12+

12+

12+

12+

12+

Flash Point, Cleveland Open Cup, °C, ASTM D92

230

230

230

240

240

240

285

Foam, Sequence I, Tendency/Stability, ml, ASTM D892

0/0

0/0

0/0

0/0

0/0

0/0

0/0

Foam, Sequence II, Tendency/Stability, ml, ASTM D892

30/0

30/0

30/0

30/0

30/0

30/0

30/0

Four-Ball Extreme Pressure Test, Load Wear Index, kgf, ASTM D2783

47

47

47

48

48

48

48

Four-Ball Extreme Pressure Test, Weld Load, kgf, ASTM D2783

200

200

250

250

250

250

250

Kinematic Viscosity @ 100 C, mm2/s, ASTM D445

8.8

11.2

14.7

19.0

24.1

30.6

39.2

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

68

100

150

220

320

460

680

Pour Point, °C, ASTM D97

-27

-24

-24

-24

-24

-15

-9

Rust Characteristics, Procedure B, ASTM D665

PASS

PASS

PASS

PASS

PASS

PASS

PASS

Viscosity Index, ASTM D2270

101

97

97

97

97

96

90



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
