Mobil SHC 500 Series

Hydraulic Oils

Mobil SHC™ 500 Series oils are exceptional performance hydraulic oils formulated from synthesised, wax-free hydrocarbon base fluids combined with a carefully engineered super-stabilised additive system. They are exceptionally high quality, wide-temperature, shear-stable hydraulic oils with controlled low-temperature pumpability properties and maximised anti-wear protection for high-pressure vane, piston and gear pumps. The products exhibit very high viscosity indexes contributing to their excellent low and high temperature performance making them an excellent choice for equipment that is subjected to a wide range of start-up and operating temperatures. The Mobil SHC 500 Series oils exhibit outstanding shear stability allowing their use in high-pressure, high-temperature operating environments for extended periods of time without the loss of critical lubrication characteristics.



The Mobil SHC 500 Series oils help provide long oil/filter life and optimum equipment protection, which can reduce both maintenance and product disposal costs. They were developed in conjunction with the major OEMs to meet the stringent requirements of severe hydraulic systems using high pressure, high output pumps as well as handling the critical requirements of other hydraulic system components such as close clearance servo-valves and the high accuracy numerically controlled (NC) machine tools. These products meet some of the most rigorous performance requirements of a wide range of hydraulic system and component manufacturers, using various multi-metallurgy designs, ensuring a single product with exceptional performance characteristics in a wide range of equipment. They are designed to work with systems operating under severe conditions where high levels of anti-wear and film strength protection are needed, yet they are formulated to work where non-anti-wear hydraulic oils are generally recommended.



Energy Efficiency logo



* The energy efficiency design is a trademark of Exxon Mobil Corporation Energy efficiency relates solely to the fluid performance when compared with ExxonMobil's standard hydraulic fluids. The technology used allows up to 6 percent increase in hydraulic pump efficiency compared with Mobil DTE 20 Series when tested in standard hydraulic applications. The energy efficiency claim for this product is based on test results on the use of the fluid conducted in accordance with applicable industry standards and protocols. Efficiency improvements will vary based on operating conditions and applications.



Features and Benefits

The Mobil SHC 500 Series hydraulic oils exhibit outstanding low and high temperature performance helping to provide an extra margin of equipment protection above and beyond the capabilities of comparable mineral oil-based products. Their excellent oxidation resistance allows extension of oil and filter change intervals while assuring exceptionally clean systems and trouble-free operation. Their high level of anti-wear properties and excellent film strength characteristics result in exceptional equipment performance that helps prevent unplanned equipment breakdowns, and maximize equipment uptime, which can enable potential improvements in production capacity. Their controlled demulsibility permits the oils to work well in systems contaminated with small amounts of water yet readily separate large amounts of water.



Features

Advantages and Potential Benefits

Design-Specific Synthetic Base stock

Helps extend service intervals

Cleaner system and reduced close-tolerance valve sticking compared to conventional products

Helps improve filterability

Exceptional Anti-wear

Helps reduce wear of components

Helps protect systems using various metallurgy

High Viscosity Index

Wide temperature range performance

Helps to ensure equipment protection at cold start-up temperatures

Helps protect system components at high operating temperatures

Outstanding Oxidation Stability

Helps provide long oil and equipment life, which can extend filter life

Excellent Corrosion Protection

Helps prevent internal hydraulic system corrosion

Helps reduce the negative effects of moisture in systems

Helps provide corrosion protection of multi-metallurgy component designs

Very Good Multi-metal Compatibility

Helps optimize inventory requirements

Meets a Wide Range of Equipment Requirements

One product can replace several helping to optimize inventory requirements and mitigate potential product misapplication

Excellent Air Separation Characteristics

Helps reduce foaming and it's negative effects

Controlled Demulsibility

Provides systems protection and lubrication where small quantities of moisture are present

Readily separates larger quantities of water

Innovative Keep Clean Properties

Helps reduce system deposits and potential sludging

Helps protect critical components such as servo-valves, improving system response and minimizing valve sticking



Applications

     •  Hydraulic systems prone to deposit build-up such as sophisticated Numerically Controlled (NC) machines, particularly where close clearance servo-valves are used

     •  Systems employing multi-metal component designs

     •  High pressure vane, piston and gear pumps

     •  Systems where cold start-up and / or very high operating temperatures are typical

     •  Where small amounts of water are unavoidable

     •  In systems containing gears and bearings

     •  Systems requiring a high degree of load-carrying capability and anti-wear protection

     •  Applications where thin oil-film corrosion protection is an asset such as in systems containing moisture



Specifications and Approvals

This product has the following approvals:

524

525

526

DENISON HF-0

X

X

X

DENISON HF-1

X

X

X

DENISON HF-2

X

X

X



Properties and Specifications

Property

524

525

526

527

Grade

ISO 32

ISO 46

ISO 68

ISO 100

Brookfield Viscosity @ -18 C, mPa.s, ASTM D2983

923

1376

2385

4500

Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130

1B

1B

1B

1B

Density @ 15 C, kg/l, ASTM D4052

0.853

0.852

0.854

0.858

Emulsion, Time to 40/37/3, 54 C, min, ASTM D1401

20

20

20

Emulsion, Time to 40/37/3, 82 C, min, ASTM D1401

20

FZG Scuffing, Fail Stage, DIN 51354

9

10

11

11

Flash Point, Cleveland Open Cup, °C, ASTM D92

234

238

240

243

Foam, Sequence I, Stability, ml, ASTM D892

0

50

0

0

Foam, Sequence I, Tendency, ml, ASTM D892

50

50

50

50

Foam, Sequence II, Stability, ml, ASTM D892

0

0

0

Foam, Sequence II, Tendency, ml, ASTM D892

50

0

50

50

Foam, Sequence III, Stability, ml, ASTM D892

0

0

0

0

Foam, Sequence III, Tendency, ml, ASTM D892

50

50

50

50

Kinematic Viscosity @ 100 C, mm2/s, ASTM D445

6.4

8.54

11.52

15.94

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

32

46

68

100

Pour Point, °C, ASTM D97

-56

-54

-53

-52

Rust Characteristics, Procedure B, ASTM D665

PASS

PASS

PASS

PASS

Viscosity Index, ASTM D2270

144

154

158

160



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
